Monoblock Refrigeration Unit, Air Cooled Condensers, Unit Cooler

Description

Monoblock refrigeration unit integrates evaporator, condenser, compressor, electrical control units into one compact body. ONLYKEM brand monoblock refrigeration unit is equipped with famous brand compressors and refrigeration parts. The high efficient heat exchanger is made with grooved copper tube and aluminum fins, which makes it very efficient in heater exchange ability with the self-adapting property. Our monoblock refrigeration unit is compact in structure, so the installation is extremely simple. It is not only guarantees better air distribution but also provides more storage space. Our monoblock refrigeration unit is very suitable for small cold storage room.

High Quality Monoblock Refrigeration Unit

Monoblock Refrigeration Unit Specifications

	Series	Model	Capacity	Temp1	Temp2	Volts	Compressor		Current	Max Current	Air Flow (m³/h)		Kg
	Series	Model	W	m³	m³	V	HP	Kw	A	A	Condenser	Evaporator	Kg
0°C	100	OKM1001M	833	6	4	230/1/50	1/3	0.25	3.1	4.1	780	820	56
		OKM1002M	1011	9	7	230/1/50	1/2	0.4	4.8	6.2	780	820	58
		OKM1003M	1252	12	9	230/1/50	1/2	0.4	3.7	5.2	780	820	59
		OKM1004M	1458	14	10	230/1/50	5/8	0.5	4.2	6.1	780	820	60
	200	OKM2005M	1721	18	14	230/1/50	7/8	0.65	4.7	9.5	1560	1620	85
		OKM2006M	1976	22	17	230/1/50	1	0.7	6	8.2	1560	1620	88
		OKM2007M	2223	29	21	400/3/50	1 1/2	1.1	3	5.4	1560	1620	90
	300	OKM3008M	2843	37	29	400/3/50	1 3/4	1.3	3.1	5.2	1780	1780	98
	300	OKM3009M	3712	44	35	400/3/50	2	1.5	3.9	6.6	1780	1780	100
	400	OKM4010M	4314	57	46	400/3/50	2 1/4	1.65	4.2	8.8	4540	4540	110
	400	OKM4011M	5059	72	58	400/3/50	3	2.2	4.8	9.8	4540	4540	112
	500	OKM5012M	5777	83	66	400/3/50	3 1/2	2.6	5.7	11.9	6520	6520	115
	500	OKM5013M	6664	95	76	400/3/50	4	2.95	6.5	12.4	6520	6520	125

-20°C	100	OKL1001L	539	2.5	2	230/1/50	3/4	0.55	4.4	6.1	780	820	58
		OKL1002L	784	5	4	230/1/50	1	0.7	4.5	6.2	780	820	59
		OKL1003L	1089	8	6.5	230/1/50	1 1/2	1.1	6.8	10.8	780	820	60
	200	OKL2004L	1200	11	8.5	230/1/50	1 1/2	1.1	6	11.7	1560	1620	85
	200	OKL2005L	1300	15	10	400/3/50	1 3/4	1.3	2.5	5.4	1560	1620	88
	300	OKL3006L	1491	22	15	400/3/50	1 3/4	1.3	2.8	4.6	1780	1780	98
	300	OKL3007L	1986	27	19	400/3/50	2 1/2	1.8	3.4	7	1780	1780	100
	400	OKL4008L	2483	35	25	400/3/50	3	2.2	4.3	8.5	3480	3480	115
	400	OKL4009L	2697	39	28	400/3/50	4	2.95	5.1	9.5	3480	3480	117
	500	OKL5010L	3918	65	46	400/3/50	5	3.7	6.7	14.4	6520	6520	145
	500	OKL5011L	5349	89	64	400/3/50	7 1/2	5.5	8.4	16.5	6520	6520	145

Monoblock Refrigeration Unit Features

Integrated design, pre-equipped refrigeration components in factory
Full automatic intelligent electronic control
Compact Size
Famous brand components
Total accessibility
Energy saving
High reliability
Optimum use of room space
Long service life

About ONLYKEM

Onlykem Technology Co., Ltd had been dedicated in manufacturing and supplying high quality cold room and refrigeration unit solutions to worldwide customers for over 10 years. We have over 20 professional cold room experts and 8,000 square meters factory. Our innovative, high quality products and solutions include cold room, freezer room, condensing unit, air cooled condenser, unit cooler, cold room door and PU panel, etc. We had provided many types of effective and states of the cold room and key parts to over 36 countries.

ONLYKEM is not only manufacturing best quality cold rooms and refrigeration units but also providing professional custom design, fabrication and installation service. OEM, ODM are also available. If you have any questions or inquiries, please fill and submit the following form, we will reply as soon as possible.
